Product Description
- Lightweight and Fast
- Efficient 900W / 50-60Hz Motor
- Coolant System
- Ergonomic Grip
- One Side Switching
- Special alloy frame, total weight only - 8.5kg
- Integrated Gearbox / Slide system
TECHNICAL DATA:
- Annular Cutters: 12 - 30mm Dia
- Twist Drills: 1 - 13mm Dia
- Stroke: 90mm
- Weight: 8.5kg
- Magnetic Force: 1200kg
- Power: 900W
- Speed (no load): 775min-1
- Speed (load): 400mim-1
- Spindle: 19.05mm Weldon
- Voltage: 220 - 240V / 50 - 60Hz
Lightest corded Ø 30 mm Magnetic Drilling Machine:
-- Most compact in class
-- Incredibly easy to handle
Direct spindle drive and integrated tool cooling and lubrication
Integrated slide and one-speed gearbox for:
-- High accuracy
-- Enlarged lifecycle
-- Minimal vibration
High precision height adjustment for:
-- Low maintenance
-- Minimal wear correction
Strong dual coil CNC machined magnet
Product Information Sheet (PDF)
